Cov pob zeb pob zeb ua ntej yog ua ntej- faus lossis xa tawm - teeb tsa hnyav- lub luag haujlwm kev sib txuas ntawm cov khoom sib txuas rau hauv cov pob zeb ua kom hloov cov khoom zoo li qub, dynamic, thiab seismic loads nyab xeeb ntawm cov pob qij txha. Tsim los ntawm precision forging, txias taub hau, thiab CNC machining, cov thauj tog rau nkoj sib txuas ncaj qha rau hauv precast phab ntsa vaj huam sib luag, kab, kab teeb, thiab cov hauv paus hauv paus. Lawv muab kev txhim khu kev qha thauj mus los hauv kev sib txuas hauv tsev prefabricated, kev tsim vaj tsev engineering, thiab cov khoom siv hnyav mounting configurations.

Cov yam ntxwv tseem ceeb ntawm cov khoom

Xov Integrity:Rolled threads muab siab dua tensile thiab qaug zog tiv thaiv piv rau kev txiav threads, tswj pitch precision nyob rau hauv cyclic loads.

Load Distribution dab tshos:Forged los yog welded thauj tog rau nkoj daim hlau / dab tshos tiv thaiv rub- los ntawm kev ua tsis tiav los ntawm kev faib cov kabmob muaj zog rau hauv cov pob zeb ua vaj tse nyob ib puag ncig.

Corrosion tiv thaiv:Kub-dip galvanizing (HDG) los yog zinc flake coatings muab kev fij los yog thaiv kev tiv thaiv tiv thaiv kev ya raws thiab tshuaj lom neeg ingress nyob rau sab nrauv lossis hauv dej hiav txwv.

Weldable Shanks:Xaiv cov qib carbon steel muaj qhov sib npaug ntawm cov pa roj carbon tsawg (CEV), tso cai rau cov txheej txheem vuam ncaj qha rau cov hlua khi lossis cov phaj hlau uas tsis muaj embrittlement.

Cov ntsiab lus tseem ceeb

Parameter	Standard Range	Customization txwv
Txoj kab uas hla (d)	M12 - M36 (1/2" - 1-1/2")	Mus txog M56 (2-1/2 ")
Tag nrho Length (L)	100 hli - 600 hli	Txog li 1200 mm
Xov Hom	Metric ISO / UNC (Coarse)	Metric Fine / Custom Pitch
Xov Length (b)	30mm - 150 hli	Xov Tooj Muaj
Min. Pob Tawb Muaj Zog	C20/25 (2,500 psi)	Siab -Lub zog pob zeb > C60/75
Tensile Capacity Range	25 kN - 320 kN	Muab xam rau ib qhov project drawing

Qib & Standards

Khoom Qib:Carbon Steel (Q345B, 35 #, 45 #, 42CrMo) thiab Stainless hlau (AISI 304, AISI 316). Cov qib ASTM sib npaug (piv txwv li, ASTM A307, A36, A193 B7) muaj raws li kev thov.

Mechanical Properties:Lub zog tawm los ntawm 235 MPa rau 830 MPa; Qhov kawg tensile lub zog spans 400 MPa rau 1030 MPa sib xws rau Cov Chav Kawm 4.6, 8.8, thiab 10.9.

Manufacturing & Test Standards:Ua raws li ISO 898-1 rau cov neeg kho tshuab fasteners, ACI 318 cov kev cai rau anchoring rau pob zeb, thiab EN 1992 (Eurocode 2) cov qauv tsim.

Load & Design Considerations

Hom Failure:Cov kws tsim qauv tsim qauv yuav tsum ntsuas cov pob zeb ua pob zeb tawg, steel tensile/shear rupture, rub- tawm, thiab sab- lub ntsej muag tawg thaum lub sij hawm tsim.

Ntug Distances & Spacing:Yam tsawg kawg ntawm ntug qhov deb thiab thauj tog rau nkoj- rau- thauj tog rau nkoj qhov sib nrug yuav tsum tau tswj kom tsis txhob muaj kev sib tsoo pob zeb kev ntxhov siab thiab kev sib cais ntxov ntxov.

Dynamic & Seismic Factors:Cyclic qaug zog thiab seismic hloov chaw yuav tsum tau txo cov khoom siv rau qhov muaj peev xwm nominal; qhia meej 42CrMo alloy variants rau siab -kev co dynamic setups.

Daim ntawv thov

Precast Sandwich Phab Ntsa Panels & Facade Fixings:Hloov tawm- ntawm- dav hlau cua thiab lub ntiajteb txawj nqus; siv stainless hlau los yog kub-dip galvanized tiav los tiv thaiv thermal bridging thiab corrosion.

Industrial Kem-rau-Foundation Base Phaj:Kev ruaj ntseg hnyav precast lossis steel kem tiv thaiv lub sijhawm khoov siab thiab shear rog siv siab -lub zog alloy variants (Property Class 8.8/10.9).

Choj Girders & Highway Barriers:Absorbs siab - cuam tshuam dynamic thiab seismic quab yuam nyob rau hauv infrastructure, featuring hnyav corrosion tiv thaiv ib puag ncig raug thiab nruam vehicular vibration.

Heavy Machinery Flooring Mounts:Anchors dynamic industrial khoom siv precision socket anchors thiab tsis yog -shrink grout los tiv thaiv kev khiav hauj lwm khiav hauj lwm thiab cyclic qaug zog.

Cov qauv hlau- mus rau - Kev Hloov Pauv:Muab cov kev thauj khoom tas mus li rau kev sib xyaw shear thiab tensile stresses thaum koom nrog cov txheej txheem steel framing rau precast pob zeb phab ntsa siv weldable shanks.

Zoo & Kev Tshuaj Xyuas

Raw Material Traceability:Spectrometric tshuaj muaj pes tsawg leeg tsom xam yog ua nyob rau hauv txhua txhua steel tshav kub ua ntej ntau lawm.

Dimensional Verification:100% kev kuaj xyuas profile siv cov calipers digital, xov GO/NO-GO gauges, thiab optical comparors.

Kev puas tsuaj & Tsis yog -Kev kuaj kev puas tsuaj:Batch tensile xeem ua nyob rau hauv universal xeem tshuab; Sib nqus particle soj ntsuam (MPI) siv rau forged taub hau thiab welds kom paub txog micro-nto tawg.

Txheej Thickness Test:Sib nqus induction ntsuas ntsuas galvanizing txheej thickness los xyuas kom meej raws li ASTM A153 / ISO 1461.

Customization Options

Tailored Dimensions:Tsis yog- qauv xov ntev, txuas ntxiv shank diameters, lossis cov xov xov tshwj xeeb (UNC/UNF).

Kev Cai Geometry:Welded rebar tails, bent thauj tog rau nkoj ceg, kev cai puag phaj configurations, los yog integrated shear studs.

Kev kho deg:Kev sib txawv txheej hnyav rau kub -dip galvanizing, mechanical galvanizing, lossis passivated stainless hlau tiav.

Dab tsi cov neeg yuav khoom yuav tsum muab

Txhawm rau kom ceev cov lus hais thiab kev ntsuam xyuas, xa cov hauv qab no tsis:

Hom kev thov:Precast ua ntej - faus daim ntawv thov los yog xa tawm - nruab retrofit.

Design Loads:Yuav tsum tau tensile load (N) thiab shear load (V) (kev pab cuam load los yog qhov kawg txwv xeev).

Pob zeb Specifications:Yam tsawg kawg nkaus pob zeb compressive lub tog raj kheej / lub voos xwmfab lub zog (f'c / f_cu) thiab cov tswv cuab tuab.

Khoom siv & Finish:Cov kev cai qib steel thiab cov qauv kev tiv thaiv corrosion (xws li ISO vs. ASTM ua raws).

Quantity & Delivery Schedule:Lub hom phiaj kev ntim ntim thiab qhov chaw nres nkoj rau kev xa khoom xa tuaj.

FAQ

Q: Lub sij hawm ua tus txheej txheem rau kev txiav txim ntau ntau yog dab tsi?

A: Cov qauv tsim yuav siv sijhawm 20 mus rau 30 hnub tom qab kev pom zoo kos duab. Kev cai alloy forging lossis tshwj xeeb kub-dip galvanizing yuav xav tau 5 mus rau 7 hnub ntxiv.

Q: Cov anchors puas tuaj yeem welded ncaj qha mus rau rebar tawb uas twb muaj lawm?

A: Yog lawm, muab qhov sib npaug ntawm cov pa roj carbon sib npaug (CEV) ntawm cov khoom xaiv raug txheeb xyuas. Peb cov qib carbon steel qauv raug xaiv los xyuas kom meej weldability yam tsis muaj cov qauv degradation.

Q: Koj puas muab daim ntawv pov thawj zeb xeem (MTC) nrog cov khoom xa tuaj?

A: Yog, EN 10204 3.1 mill test daim ntawv pov thawj qhia txog cov tshuaj muaj pes tsawg leeg thiab cov txiaj ntsig kev ntsuas tshuab tau muab rau txhua pawg.

Q: Dab tsi yog qhov tsawg kawg nkaus xaj kom muaj nuj nqis (MOQ) rau kev cai -sized anchors?

A: MOQ sib txawv raws li cov khoom siv raw thiab cov cuab yeej teeb tsa, feem ntau pib ntawm 500 daim ib qhov loj rau kev cai forged variants.

Q: Puas yog thib peb - tog neeg soj ntsuam txais?

A: Yog lawm, kev tshuaj xyuas los ntawm cov koom haum ywj pheej xws li SGS, BV, lossis TÜV tuaj yeem ua haujlwm ua ntej xa khoom kawg.

Q: Yuav ua li cas thauj tog rau nkoj lub tes tsho txawv ntawm cam khwb cia-hauv phaj thauj tog rau nkoj?

A: Cam khwb cia- nyob rau hauv phaj thauj tog rau nkoj thauj khoom ncaj qha los ntawm embedded daim hlau thiab welded studs, whereas thauj tog rau nkoj lub tes tsho los yog lub qhov (sockets) siv cov xov sab hauv kom tau txais threaded rods los yog bolts tom qab qhov chaw tso.
